RC350-80 Silicon Steel Core Spooling Machine

Equipment brand: SZWADE
Equipment origin: Shenzhen, China
Equipment Name: Silicon Steel Core Coiling Machine
Equipment model: RC350-80
Device dimensions: 205CM * 130CM * 195CM
Equipment weight: 2300KG
Power supply specification: 380VAC  50/60HZ
Power consumption: 1000W
Air pressure: 6 - 7 kilograms per square centimeter
Interface Overview: Simplified Chinese and English interfaces
Production function: Circular, partly square, partly irregular shape.
Number of servo axes: 6 axes
Minimum inner diameter: 30mm
Maximum inner diameter: 260mm
Maximum outer diameter: 350mm
Steel sheet width: 10 - 80 mm
Steel sheet thickness: 0.15 - 0.5 mm
The accuracy on both sides of the core is: < 0.1mm
Discharge machine: Equipped with machinery
Maximum material outer diameter: 1200mm
Inner diameter expansion range: 450 - 520mm
Maximum load: 1T
Maximum discharge speed: 200 meters per minute
